Round,Hexagon,Square,Rectangle,Triangle,Ellipse,Eccentric Hole,Step Hole,Taper Step Hole,Octagon Hole,Six Slots Hole,Special Hole.Powerful Grip,S-slots type,Long-nose S-slots, Long Carbide,Ex
| Machine model | Headstock collet | Guide bushing | Sub collet |
| R04 | TF8 ( F8/76-511 / 101E ) | PD4 ( T9 / 3077E / 1.001 ) | TF8 |
R07 | TF15 ( F15 / 120E / 40.003 ) | TD7 ( T11/J4 / 3134E / 3.001 ) | TF15 |
| D10,F10 | TF15 ( F15 / 120E / 40.003 ) | TD10 ( T16/J6R / 3260E / 8.001 ) | |
| L10 | TF15 ( F15 / 120E / 40.003 ) | TD10 | TF8 |
| B12,B12I,B12II, | TF16 ( F16/1076 / 1212E / 40.012 ) | SD125R ( T18 / 3319E / 174.001 ) | |
| F12,B12V.B12VI,M12 | TF16 ( F16/1076 / 1212E / 40.012 ) | SD125R | TF16 |
| BL12 | BL12 | ||
| K16,A16,C16,M16 | TF20 ( F20/87 / 138E / 40.004 ) | 0201 ( T24/B238 / 3507E / 61.002) | TF20 |
| L20,L20VII,M20,B20,B20IV,A20,A320,E16J,E216,E220 | TF25 ( F25/64 / 145E ) | TD25-NS ( T28/B261 / 3602E / 22.001) | TF25 |
| A20(Non-Guide Bushing model) | BL25 | TF25 | |
| D16 | TF25 | ||
| G16,L16 | TF25 | 0201 | |
| L16V/L,16VII | TF25 | 0201 | TF25 |
| L20I,L20III | TF25 | TD25NS | |
| BL25 | BL25 | TF30 | |
| 20# | 511.001 | 510.001 | 511.001 |
| L25,E225,E225J,F25 | TF30 (F30/63 / 157E / 40.006) | CD25 (T34/B227 / 3733E /451.001) | TF30 |
| A32,C32,E232,E32/32IV,E32K,G32,L32,M32 | TF37 TF37SP ( F37/740 / 1536E) | TD32 (T42 / 28.01 ) | TF37 TF37SP |
| FL32 | TF37SP | TF37SP | |
| L32 UPGRADE 38mm | TF43 ( F43 / 511.024) | TF43 | |
| BNA-42GTY | TF48 ( F48/81 173E 231.009) | ||
| FL42 | TF48 | TF48 |
